(336/364) 2023-11-26_20-46-40.jpg
Tabs worked - narly burs..
335: 2023-11-26_20-39-53.jpg
334: Cutting the index plate
333: Re did the lapping plate magnet project with bigger magnets.
332: Drill grinder attachmet. Grove milled.
331: Drill grinder attachmet. Indicated in to cut grove..
330: Drill grinder attachmet.
329: Thread is correct - need to turn the seat.
328: Adapter installed.
327: Made an adapter (on the right) for Norma.
326: This BBQ won't rock any more!
337: Deburred and adjustable index point for the drill sharpener.
338: 2023-11-26_21-06-23.jpg
339: Tool holder to boring head - needs a trim for the shoulder.
340: Tool holder to boring head - needs a trim for the shoulder.
341: Actually well done - the dovetail has a flexture - it is tightened with 3 cone head grub-screws that press on small ball bearings.
342: There is some backlash in the adjustment - but I think that is par for the course. Stuff out of China is still cheap - but quality seems to be going up.
343: I put some threads on the oil can spout ( focus never holds still)..
344: The aluminum tip is no longer smooth and round - thus does not seal the oil-ball oilers..
345: Side project - this tilt table was made for 12mm - just a bit too small for 1/2" clamp hardware.
346: The same for the top - widening the slots for 1/2" hardware - (12mm will still work)..
